CNC Laser Cutting Turnstile Attendance SS304 Tripod Turnstile Gate IP45

Name: CNC Laser Cutting Turnstile Attendance SS304 Tripod Turnstile Gate IP45
Brand: Zento
SKU: ZT-809A
Rating: 4.7 (196 reviews)

Product Details

Place of Origin: Shenzhen China

Brand Name: Zento

Certification: CE ISO9001 ROHS

Model Number: ZT-809A

Payment & Shipping Terms

Minimum Order Quantity: 2pcs

Price: Negotiable

Packaging Details: carton/wooden box

Delivery Time: 3-7days

Payment Terms: T/T, Western Union,Paypal

Supply Ability: 100 pcs per week

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                Tripod Turnstile Gate IP45, SS304 turnstile attendance, CNC Laser Cutting turnstile attendance


Closing Time:	2S	Color:	Silver
Material:	304 Stainless Steel	Passage Width:	550mm
Communication Interface:	RS485/Relay Signal	Product Name:	Tripod Turnstile Gate
Protection Level:	IP54	Size:	1400280980mm
Warranty:	Life Time Technical Support	Working Humidity:	≤95%

Closing Time:	2S
Color:	Silver
Material:	304 Stainless Steel
Passage Width:	550mm
Communication Interface:	RS485/Relay Signal
Product Name:	Tripod Turnstile Gate
Protection Level:	IP54
Size:	1400280980mm
Warranty:	Life Time Technical Support
Working Humidity:	≤95%

CNC Laser Cutting Turnstile Attendance SS304 Tripod Turnstile Gate IP45

Metro Station Waist Height Tripod Turnstile Gate System Intelligent Attendance Entrance

Metro Station Waist Height Tripod Turnstile Gate System Intelligent Attendance Entrance

tripod turnstile is a controlling device. which designed for pedestrian access control. It used in gymnasium, tourist attractions, factory, train, station, and so on. Indoor and outdoor.Tripod turnstile is a most effective-cost way to control pedestrian access. high reliability.

This series of automatic tripod turnstiles adopt the unique technology of our company--precise photoelectric registration and gear structure to orient the closure. The turnstile will be unlocked and reset by the specific motor. The closure is precise and stable. Furthermore, these products adopt standard electrical sockets, which can be integrated with magcard, code cards, ID cards, IC cards, etc.

CNC Laser Cutting Turnstile Attendance SS304 Tripod Turnstile Gate IP45 0

Parameters

Barrier Arm material	SS304
Production Process	CNC Laser Cutting
Size	1200280980mm
Power input	AC100-240V,50/60HZ
Operation voltage	DC24V, 3A, Power: 40W
Electromagentic	Duty Cycle 100%
Barrier Arm Lenght	510-550mm
Arm Max Applied Force	55Kg
Passage direction	Single directional/Bi-directional(Optional)
Throughput Rate	30-35 persons/minute
Operating time	0.2 seconds
Automatic Reset Function	Automatically locked within set time(Adjustable)
Operation Humidity	0~95%(No Freezing)
Operation Temperature	-15℃~+60℃
Operation Eenvironment	Indoor,Outdoor(Shelter)
Protection Level	IP45
Communication interface	TCP/IP
MCBF	5,000,000 Cycles

Functions & Features

Card reader available, support WEIGAND 26/34 communication card reader.
Bi-directional pass/any single direction
pass(adjustable).
Arm auto-drop when power off and auto rise up when power on and auto stop on an obstacle.
Traffic light indicator/Pass direction indicator.
Alarm light available(optional function)/Remote control available (optional function)/Counter available (optional function).
RS232 socket available which can connect to a computer. It can also connect to a computer by Internet LAN socket (Optional function).

Advantage:

1.The electric control adopts DC motor to drive stable and reliable, and has low failure rate.

with ultra high light traffic indicator.

2.Remind function:

In the case of a man who does not swipe card, the alarm will prompt the traveler to swipe card.

3. Alarm Function:

when a pedestrian swipes the card, the device alarms the alarm.

4.Check the following function:

The device will alarm when first people swipe card when second people doesn't.

5.The automatic delay function:

prevent people not hitting.

6.Various control functions:

By set the setting, the brake machine can be set at special time to be a regular open mode.

It satisfies a large number of people.

7.The mode of choice:

To meet the different requirements, set up as a two-way credit/one-way credit card/free pass.

8.Various control functions:

external button, remote control, bar code,IC or ID card, QR Code, ESD Tester, Face recognition,etc.

Application

This model is widely used in bus station, port, subway, factory, mansion, residential area, hotel, companies and so on any place that requires a smart flow control.
