Flap Turnstile Barrier
VR
  • Products Details

Having invested a great deal of funds to technology research and product development,Shenzhen Zento Traffic Equipment Co., Ltd. has successfully worked out School Gate Security Entrance Management RFID Card Access Control System Vertical Flap Barrier Turnstile Gate. After years of growth and development, we have been mastering the manufacturing technologies maturely. As its advantages continue to be discovered, it is continually used in more field(s) such as Turnstile. Thanks to the multiple characteristics that have been tested by our QC inspectors,Turnstile Access Control Gate & Parking System Equipment has a wide application in different fields mainly including Flap Type Turnstile.We hold a firm belief that the broad application of the product will drive the industry to develop and advance rapidly.

Place of Origin:Guangdong, ChinaBrand Name:Zento
Model Number:ZT-955AProduct name:Sliding Type Entrance
Material:304 Stainless SteelMaterial Thickness:1.5 mm
Size:430*330*980 mmPassage Width:Q600mm
Operating temperature:-25℃ ~ +60℃, RH ≤90%Lifespan:Above 8 million times
Direction:Bi-directionalPass Speed:35-40P/min
Way of opening:ID / IC card reader, face,fingerprint ect

Product Description

Unique Design Appearance Low Noise Operation Access Control Flap Barrier Gate Turnstile

Flap barrier gate, also called wing gate is one of the passage management equipment, mainly used for pedestrian passage management; it has the characteristics of fast opening, safety, and convenience, and is an ideal managing and channeling device for high-frequency pedestrian access; it has been widely used in airports, subway stations, and railway stations , docks, scenic
spots, parks, student dormitories, pedestrian passages, etc.

Function:

1. Functions of breakdown self-checking and alarm warning, very convenient for customers’ maintenance and use.
2. Program operation mode of equipments through the little button inside the main board.
3. Double Anti-Pinch function from both machine structure and induction. Stops automatically if there is something in the way during the return /rest of the doors. If there is default time delay, it will have its second return (till it comes back to where it should be), and the force is very weak
4. Anti-rushing function: without having received the signal of opening up, the doors lock automatically.
5. Doors can be adjusted into synchronization (only for double-locks)
6. Automatic returning/resetting function: when the barriers open up, if people do not pass by within the time allowed, system will cancel the right of pass for this time. 7. Adjust it to normal open or normal closed to meet the different requirements of different fields.
7. Can be linked to many kinds of card-reading equipments and work when it has received the signal of electricity relay switch.
8. One-way and two-way in and out control of passer
9. Carry out distant control and management by directly operating computer.
10. Automatic returning /resetting when there is time delay. Normally speaking, it returns/resets five seconds after its opening.
11. When the electricity is cut off, the access opens automatically, and closes automatically when the electricity is linked.Meet the requirements of fire-fighting.
13. Sound and lights alarming: including break-in and opposite direction intrusion,and so on.
12. Counting function (optional)
13. Anti-Pinch function (four pairs of infrared)
14. Accurate logical judgment, Irda returning function (four or six pairs).
15. Speech output, human voice warning the right passing. (Optional

Parameters
Framework
304 Stainless Steel
Dimensions
430*330*990 mm
Passage wideth
600mm
LED indicating light
One
Card-reading window:
Two
Rated power
120W
Operating temperature
-25℃ ~ +60℃, RH ≤90%
Related humidity
≥90%RH
Comunication Interface
RS485,distance ≤1200m
Power supply
AC 220V/110V ±10% 50/60MHZ (optional)
OpeningTransit speed:
35-40persons per minute
Service Life
5,000,000 cycles
Details
Other Models
Related Product
Why Choose Zento
CE &ISO9001 Verified Certifications
Package & Delivey
