The core competitiveness of a company is its capabilities in research and development.Shenzhen Zento Traffic Equipment Co., Ltd., as a technology-driven enterprise, has been striving forward to enhance our R&D capabilities and successfully developed High recognition rate Security access control face recognition machine. It turns out that the application of the technology plays an important role in deciding the performance of the product. At present, it can be widely seen in the field(s) of Time Recording. Shenzhen Zento Traffic Equipment Co., Ltd. adhere to the corporate philosophy of 'people orientation' and always advocate honesty, innovation, and fairness. We hope to occupy an important position in the industry and become one of the most leading brands in the future.
| Type: | Biometric Time Recording | Biometric Measurement: | Face |
| Place of Origin: | Guangdong, China | Brand Name: | Zento |
| Model Number: | ZT-SOE | Product Name: | Face recognition machine |
| Serial communication interface: | 1 RS232 interface | Screen parameter: | 1024 * 600 7 inches |
| Video: | HDMI 2.0 type - A interface 1 | Local-storage: | Flash memory 8G |
| Network interface: | 1 RJ45, 10M/100M adaptive Ethernet port | Face detection: | At the same time support testing and tracking of 5 people |
| Identification distance configuration: | support |
High recognition rate Security access control face recognition machine
Product presentation
The integrative terminal of face recognition uses the world's leading face detection and recognition algorithm, runs it in high performance embedded platform, coordinates 200W pixel camera, realizes face detection, face tracking, and face recognition. And it can present the corresponding feedback on the screen. The product can recognize 5 people at the same time, the farthest can recognize the human face as far as 5 meters, and face tracking and detection takes about 20ms. Face feature extraction takes about 300ms; face comparison takes about 0.1ms.
And it has good robustness to light and wear glasses and so on. This product can be equipped with RFID card module, so the system can be realize to use card and face recognition. This product supports a variety of hardware functional interfaces (including: HDMI high-definition output, serial port input/output, network interface/ Wi-Fi access); It has a complete software interface (including: device management, personnel/photo management, record view, etc.).
At the same time, this product can connect with the company developed a variety of applications, such as: attendance system, access control system, visiting system, real name certification.
Suitable for office area, gate passage, hotel, office building, school and other places where face recognition gate is needed.
l Support external HDMI large screen;
l Support external ID card / RFID reader;
l Support serial port input and output, support Wiegand output, output content supports configuration;
l Support the RFID card , can also achieve the integration of human cards;
l Dynamic face detection based on video stream and tracking recognition algorithm are adopted;
l Support to store 50, 000 face photos, 1 million recognition records;
l The accuracy rate of 1: N recognition is high (99.7% under 97% pass rate).
l Recognition speed is fast, face tracking and detection takes about 20ms time, facial feature extraction takes about 300ms, and face comparison takes about 0.1ms.
l Support stranger detection, stranger level can be configured;
l Support face recognition or stranger detection of the scene of the photo preservation;
l Support interface docking;
l Support customization;
l Support screen display content configuration;
l Support identification distance configuration.
Product specification sheet
Screen parameter | 1024 * 600 7 inches | |
Video camera | Resolution | 200W pixel |
Aperture | 2.4 | |
Focal length | 6mm | |
White balance | Automatic | |
Interface | Audio | 1 channel audio input ( line in ); 1 channel audio output ( line out ) |
Video | HDMI 2.0 type - A interface 1 | |
Local-storage | Flash memory 8G | |
Serial communication interface | 1 RS232 interface | |
Reset interface | Built - in reset button | |
Wireless communication | 2.4G WI-FI ( optional ) + 13.56M IC card reader ( optional ) | |
Network interface | 1 RJ45, 10M/100M adaptive Ethernet port | |
Function | Face detection | At the same time support testing and tracking of 5 people |
1:N face recognition | Under the condition of supporting 97 % pass rate, 99.7 % pass rate | |
1:1 face comparison | Support optional card swiping module to achieve 1:1 face comparison | |
Stranger test | Support | |
Identification distance configuration | Support | |
UI interface configuration | Support | |
Device interface | The interface includes equipment management, personnel/ photo management, record query, etc. | |
Mode of deployment | LAN usage | |
Power supply | DC12V(±10%) | |
Working temperature | -10℃--+55℃ | |
Working humidity | 10%--90% | |
Power consumption | 10W MAX | |
Weight | 5.9Kg | |
FAQ
1. What is the strength of your company in this industry?
We are the top 5 in turnstile field in China, more than 120 employees and over 20 senior R & D technical persons to ensure the gate could work well in different environment, power supply and current. Experienced foreign trade business team can help you to deal with any emergency before, during and after the sales. The brand ZENTO is highly recognized in Southeast Asia.
2. What is your pricing strategy?
For overseas markets, we will use competitive prices to support a strong distributor in each area, and gradually establish overseas service agency, as a good opportunity, some long-term cooperation partners will compete with us to sign the annual cooperation agreement (including execution price).
3. How about Quality Control?
IOS9002 could help us to realize the factory management control and our ERP system can help us to control the cost of procurement links effectively, so we can provide a good price. New test system could do uninterrupted fatigue testing to ensure its using life. Pre-shipment inspection and third-party supervision are available.
4. How about some special design?
That’s our advantage of design new gate or barrier according to your real situation to make different size, software and features. Video call available during design and communicate in time during this procedure.
5. Do you have agency for after-sales service?
Any question about delivery goods, you could find our sales anytime. For installation, we will offer instruction video to help and if you face any technical question, welcome to contact with us to have a face time to solve it.
6. What time do you need to delivery?
Commonly to say, 5-7 working days after payment could delivery for common orders, but it depends the order quantity. We could talk about this question before final payment.
7. How about the payment method?
Standard products: 30% deposit, 70% balance payment before shipment.
Customized products: 50% deposit, 50% balance payment before shipment.
Contract amount more than USD15000: 50% deposit, 50% balance payment before shipment.
T/T, PayPal, Credit guarantee order
8. How to ship?
By air or by sea, quantity over 10 sets better to choose by sea to reduce cost.
9. How about your package?
Exported product: Wooden case package of Export exempted from inspection plus pearl wool and plastic wrap
Domestic: Bubble wrap plus carton or pearl wool plus wooden packaging.
10. How long is your warranty period?
13 months, add 10% of contract amounts since the second year,15% of the contract amounts since the third year.
