Hydraulic Bollard
VR
  • Product Details

Retractable Traffic Safety Parking System Anti Crash Automatic Security Bollard is designed in different styles and varied sizes. In order to guarantee Retractable Traffic Safety Parking System Anti Crash Automatic Security Bollard performance, the adopted technologies are technically useful and feasible. Depending on its properties, the product is widely applied in the field(s) of Traffic Barrier. Shenzhen Zento Traffic Equipment Co., Ltd. will continually adopt positive marketing strategies to develop new markets, therefore establishing a more sound sales network. Moreover, we will reinforce the scientific research and try hard to gather more talents to focus on the research and development of new products. Our wish is to become one of the most competitive enterprises in the market.

Place of Origin:Guangdong, ChinaBrand Name:ZENTO
Product name:Hydraulic road bollardsMaterial:304 Stainless Steel
Application:Roadway SafetyWarranty:1 Year
Normal work life:over 5 yearsRaising/lowering speed:3-6s(adjustable)
Diameter:275/220mmraised height:600-800mm(optional)
system control:hydraulic and electric controlLamp belt:LED lamp(Acrylic light circle)


Retractable Traffic Safety Parking System Anti Crash Automatic Security Bollard

Hydraulic automatic bollard mainly consists of oil pump unit and steel frame construction. It use soil pressure as dynamic to realize the rise/fall of bollard.As a moving device, it is usually installed at vehicle entrance/exit. It rises to block the vehicle and falls the ground level to authorize free passing.









Application:

Scientific and educational units: schools, computer rooms, research centers, libraries, etc.;

Leisure and entertainment venues: parks, scenic spots, pedestrian streets, municipal squares, playgrounds, etc..

Traffic: bus station, railway station, subway station, airport, etc..

Business service places: hospitals, banks, hotels, clubs, commercial buildings, etc..

Office space: large office buildings, public inspection units, hydro power and oil and gas units and other government agencies.





















Technical Parameters

Color

Silver

Raising/lowering speed

3-6s(adjustable)

Diameter

275/220mm

raised height

600-800mm(optional)

Material

304 stainless steel

Control mode

remote control(<50m)

system control

hydraulic and electric control

Working temperature

-30℃~75

Embedded cylinder depth

1100mm

Lamp belt

LED lamp(Acrylic light circle)

 Power Supply

220V/380V

thickness

6mm

weight

100-155kg

anti-collision levels

K6

service life

3 million times

Drainage mode

natural drainage+External drainage system

Feature

1. Anti-collision:It can be used normally after being hit by a 12-ton vehicle.

2. Anti-destructive power:After being hit by a 16-ton vehicle, Hydraulic road bollards deformation.

3. internal structure:With load-bearing steel beam and column, anti-collision steel beam column, 4 navigation rods

4. Can be manually lowered in the event of a power outage

5. Linkage interface

6. Reversible operation according to requirements during ascent and descent

7. Noise during operation of the device≤60 dB

8. Waterproof integrated hydraulic drive

9. Control solenoid valve 24V

10. Control box display text adjustable (up, down, start, time control adjustment)

11. Display text in English

12. Water immersion performance:no leakage during 48 hours and normal lifting

13. Anti-corrosion performance level: 9



Detail

1. Automatically raise/lower/stop.The automated bollards adopt a heavy duty hydraulic power pack and operate by integrated control.Easy to install and operate. Built-in led flashing lights and reflective tap in the bollard head to ensure visibility and safety.

2. Variable frequency controller. Adopt variable frequency controller,the raise/lower speed 3-6s is adjustable.It can stop emergently during raising/lowering process. The control signal is electric transmission, quick and reliable.

3. Firm foundation plate.Thicken seamless 304 stainless steel with strong bearing capacity more than 40 tons. Rust protection and distortion resistance.

4. Built-in valve.In case of emergent issue for example power failure, the obstacle can be lowered by relief valve manually to make sure the passage of pedestrians and vehicles in not affected.

5. Adopt high quality great power motor, the bollards can raise/lower speedy,work stable and durable with 1500 cycles working frequency per day.The motor can be disassembled for easy maintenance.

6. Multiple security protection.Use high pressure air rifle to seal up the vent,the motor can work when soaked in water with electricity leakage protector.



Installation steps

1. Cut the ground surface and excavate,the foundation base need around 800mm and 1130mm.

2. Fill the bottom with 20-30mm pebble and sand as water seepage stratum.

3. Embed the bollard,make sure the head of the bottom is at the same level with the horizontal ground.

4. Install the wiring tube and drainage pipe.Make sure each wire should be secured by waterproof tape to avoid water vapor permeated into the wire.

5. Power on to test. Make sure the bollards can work well.Then cover the head of the bollard to avoid the concrete dirty it.All the drainage pipe hole need to be covered by structural adhesive.

6. Pour the concrete into the foundation base.Be careful to avoid the movement of bollard.

7. Tidy up the bollard head and ground surface, complete installation

Drainage method:

1. Use artificial drainage or electric pumping mode, need to dig a small pool near the column, regular manual and electric drainage.



2. Use the natural drainage mode to connect directly to the sewer.

  A. At the installation junction (two), dig out two square grooves

square grooves: (user-defined)mm (L)* 1000mm(W)* 1330mm(H)



  B. Fill the bottom of the groove with 200mm-high concrete, the precision requirement of the horizontal plane is high(Lifting column rack can be subjected to force), and at the middle of the side of the trough, leave a PVC# for drainage.

Company Information



Our Services



FAQ

FAQ



1.       What is the strength of your company in this industry?

We are the top 5 in turnstile field in China, more than 120 employees and over 20 senior R & D technical persons to ensure the gate could work well in different environment, power supply and current. Experienced foreign trade business team can help you to deal with any emergency before, during and after the sales. The brand ZENTO is highly recognized in Southeast Asia.



2.       What is your pricing strategy?

For overseas markets, we will use competitive prices to support a strong distributor in each area, and gradually establish overseas service agency, as a good opportunity, some long-term cooperation partners will compete with us to sign the annual cooperation agreement (including execution price).



3.       How about Quality Control?

IOS9002 could help us to realize the factory management control and our ERP system can help us to control the cost of procurement links effectively, so we can provide a good price. New test system could do uninterrupted fatigue testing to ensure its using life. Pre-shipment inspection and third-party supervision are available.



4.       How about some special design?

That’s our advantage of design new gate or barrier according to your real situation to make different size, software and features. Video call available during design and communicate in time during this procedure.



5.       Do you have agency for after-sales service?

Any question about delivery goods, you could find our sales anytime. For installation, we will offer instruction video to help and if you face any technical question, welcome to contact with us to have a face time to solve it.
