Sliding Speed Turnstile Gate
VR
  • Products Details

Access Control System Card Swipe Reader for Entrance and Exit Full Height Barrier Sliding Turnstile Gate is designed in different styles and varied sizes. Access Control System Card Swipe Reader for Entrance and Exit Full Height Barrier Sliding Turnstile Gate provides not only excellent quality, but also very favorable price. Shenzhen Zento Traffic Equipment Co., Ltd. will continue to gather more industry elites and improve our technology to upgrade ourselves. We hope to achieve the goal of realizing independent production without relying on others' technologies.

Place of Origin:Guangdong, ChinaBrand Name:Zento
Model Number:ZT-947Product name:Sliding Type Entrance
Material:304 Stainless SteelMaterial Thickness:1.5 mm
Size:1400*330*990 mmPassage Width:Q600mm
Motor:DC Brushless MotorDirection:Bi-directional
Operating temperature:-25℃ ~ +60℃, RH ≤90%Pass Speed:35-40P/min
MCBF:5,000,000 Cycles

Product Description

Card Control Entrance
Full Height Barrier Sliding Turnstile Gate

The sliding gate housing comes out from stainless steels pressing which is good-looking, anti-rust and durable. It can be integrated with magnetic card, bar code, IC and ID card by standard electrical interface, thus good-order and civilized passing means are realized and unauthorized persons will never be allowed to get in. Meanwhile, to meet fire-control passage requirements, sliding barrier arms will open automatically if power off and there will be enough time to organize people to get out.

Founction:

1. Functions of breakdown self-checking and alarm warning, very convenient for customers’ maintenance and use.
2. Program operation mode of equipments through the little button inside the main board.
3. Double Anti-Pinch function from both machine structure and induction. Stops automatically if there is something in the way during the return /rest of the doors. If there is default time delay, it will have its second return (till it comes back to where it should be), and the force is very weak
4. Anti-rushing function: without having received the signal of opening up, the doors lock automatically.
5. Doors can be adjusted into synchronization (only for double-locks)
6. Automatic returning/resetting function: when the barriers open up, if people do not pass by within the time allowed, system will cancel the right of pass for this time. 7. Adjust it to normal open or normal closed to meet the different requirements of different fields.
7. Can be linked to many kinds of card-reading equipments and work when it has received the signal of electricity relay switch.
8. One-way and two-way in and out control of passer
9. Carry out distant control and management by directly operating computer.
10. Automatic returning /resetting when there is time delay. Normally speaking, it returns/resets five seconds after its opening.
11. When the electricity is cut off, the access opens automatically, and closes automatically when the electricity is linked.Meet the requirements of fire-fighting.
13. Sound and lights alarming: including break-in and opposite direction intrusion,and so on.
12. Counting function (optional)
13. Anti-Pinch function (four pairs of infrared)
14. Accurate logical judgment, Irda returning function (four or six pairs).
15. Speech output, human voice warning the right passing. (Optional

Parameters
Framework
304 Stainless Steel
Dimensions
1400*330*990 mm
Passage wideth
600mm
LED indicating light
One
Card-reading window:
Two
Rated power
120W
Operating temperature
-25℃ ~ +60℃, RH ≤90%
Related humidity
≥90%RH
Comunication Interface
RS485,distance ≤1200m
Power supply
AC 220V/110V ±10% 50/60MHZ (optional)
OpeningTransit speed:
30—45persons per minute
Closing Transit speed:
25-30 per minute
Application
Sliding gate turnstile is arm at intelligent management of pedestrian access control, this kind of model often use in luxury office building, Luxury residential, subway, star hotel, and some other High-grade places.
