Hydraulic Bollard
VR
  • Products Details

Shenzhen Zento Traffic Equipment Co., Ltd. has many years rich experience in manufacturing Top Quality Anti Terrorism Traffic Barricade Bollards Parking Barrier Cheap Automatic Lifting Bollard Lamp. Traffic Barrier has won high attention and praise from the industry and market. Shenzhen Zento Traffic Equipment Co., Ltd. always stick to the core value of 'integrity and honesty' since established. We will strive forward to manufacture and provide the fine-quality products and try hard to provide the best services for our customers.

Place of Origin:Guangdong, ChinaBrand Name:ZENTO
Product name:Automatic Hydraulic Rising BollardColor:Optional
Warranty:1 YearMaterial:304 Stainless Steel
Application:OutdoorPower Supply:AC220V+/-10% 50HZ/60HZ
Certificate:ISO9001:2008Thickness:2.0-3.0mm
Raw Material:304 Stainless Steel

Products Description

Product Detail

Hydraulic automatic bollard mainly consists of oil pump unit and steel frame construction. It use soil pressure as dynamic to realize the rise/fall of bollard.As a moving device, it is usually installed at vehicle entrance/exit. It rises to block the
vehicle and falls the ground level to authorize free passing.
1. Automatically raise/lower/stop.The automated bollards adopt a heavy duty hydraulic power pack and operate by integrated control.Easy to install and operate. Built-in led flashing lights and reflective tap in the bollard head to ensure visibility and safety.
2. Variable frequency controller. Adopt variable frequency controller,the raise/lower speed 3-6s is adjustable.It can stop
emergently during raising/lowering process. The control signal is electric transmission, quick and reliable.
3. Firm foundation plate.Thicken seamless 304 stainless steel with strong bearing capacity more than 40 tons. Rust protection and distortion resistance.
4. Built-in valve.In case of emergent issue for example power failure, the obstacle can be lowered by relief valve manually to make sure the passage of pedestrians and vehicles in not affected.
5. Adopt high quality great power motor, the bollards can raise/lower speedy,work stable and durable with 1500 cycles working frequency per day.The motor can be disassembled for easy maintenance.
6. Multiple security protection.Use high pressure air rifle to seal up the vent,the motor can work when soaked in water with
electricity leakage protector.

Main Features

1. Anti-collision:It can be used normally after being hit by a 12-ton vehicle.
2. Anti-destructive power:After being hit by a 16-ton vehicle, Hydraulic road bollards deformation.
3. internal structure:With load-bearing steel beam and column, anti-collision steel beam column, 4 navigation rods.
4. Can be manually lowered in the event of a power outage.
5. Linkage interface.
6. Reversible operation according to requirements during ascent and descent.
7. Noise during operation of the device≤60 dB.
8. Waterproof integrated hydraulic drive.
9. Control solenoid valve 24V.
10. Control box display text adjustable (up, down, start, time control adjustment).
11. Display text in English.
12. Water immersion performance:no leakage during 48 hours and normal lifting.
13. Anti-corrosion performance level: 9.Technical Parameters
Raising/lowering speed
3-6s(adjustable)
Diameter
275/220mm
raised height
600-800mm(optional)
Control mode
remote control(≦50m)
system control
hydraulic and electric control
Working temperature
30℃~+75℃
Lamp belt
LED lamp(Acrylic light circle)
Drainage mode
natural drainage+External drainage system
Why Choose Us
Shenzhen Zento Traffic Equipment Co., Ltd, founded in 2004 in shenzhen, is a professional enterprises which engaged in the research and development, large-scale production and sales of high-tech innovative security and protection products around the world. Zento has become the chief supplier of intelligent security system products. With the principle of leading technology, quality first, customer supreme, Zento aims to provide satisfactory service for customers.


We have a professional sales team, management team, technical team and production team. Among them, because we have an excellent production team, we can achieve OEM/ODM, and our professional technical team can provide remote technical guidance and 24-hour technical services. At the same time, our sales team has professional knowledge and can communicate with customers. Real-time communication to help customers solve all problems.
